Noyafa NF-8209S Network Cable Tester and Tracer مع Porbe المضادة للهتلى ، Crimp ، Poe Port

Wiremap:

• Cable types: CAT5/CAT6
• Cable sequence and fault testing: Normal, open circuit short circuit, cross,etc
• STP/UTP: Both compatible
• Max range: 600m / 1,968ft

QC Test:

• Test type: 8P
• Response speed: No longer than 1 second
• Minimum recognition: 10cm / 3in

Length:

• Test line: CAT5 & 6
• Test range: 2.5 - 200m /8 - 656ft
• Accuracy: ≤20m±4.6m; 20-100m ±2.4m; >100m±3.2m

Scan:

• Cable type: CAT5 & 6
• Max signal voltage: 5V ± 1.0VP-P
• Frequency: 455KHz
• Dual mode: Analog / digital mode
• Max range: 600m / 1,968ft

PoE:

• Voltage test range: DC 5-60V
• Power supply core jumper mode: End jumper, middle jumper, 8-core power supply, unknown.
• PSE type: Non-standard, IEE802.3at/af

Port Blinks

• Full-duplex/ half-duplex recognition
• Auto-negotiation/ non-auto-negotiation
• Switch type: 10m/100m/1000m

Transmitter:

• LCD Display: 180*64 with backlight
• Language: Chinese/English
• Ports: RJ45 * RJ11
• Power supply: 3.7V 1400mAh polymer lithium battery
• Low battery power indication: yes
• Auto-off: 15/30/60min or off
• Voltage protection: DC60V
• Maxi working current: ≤200mA
• Size: 125*70*32mm

Receiver:

• Adjustable scan strength: Yes
• NCV: AC70V - 1000V 50/60Hz
• Voltage protection: DC 60V
• Maxi working current: ≤200mA
• Ports: RJ45
• Voice prompt: yes
• Headphone jack: yes
• LED: Power indication & LED lighting
• Power supply: 3.7V 1400mAh polymer lithium battery
• Size: 198*50*30mm

NOYAFA NF-8209S Instruction
